Future-Proof Power for Heavy-Duty Infrastructure
Engineered for public highway networks and heavy-duty commercial fleets, the High-Visibility Yellow 60kW-160kW DC Fast Charging Station is the ultimate scalable Level 3 solution. Manufactured in our TUV and ISO dual-certified facility, this floor-mounted powerhouse allows Charge Point Operators (CPOs) to seamlessly upgrade power modules from 60kW up to a massive 160kW as market demand grows.
Designed to stand out and survive in extreme industrial environments, it features a striking yellow IP55/IK10 enclosure for maximum safety. Equipped with a premium 7-inch anti-glare touch screen, versatile access via RFID, NFC, APP, and ISO 15118 Plug & Charge, and enterprise-grade OCPP 1.6J (TLS 1.2) security, it represents the pinnacle of OEM/ODM heavy-duty charging.
EV Charging Station Business
CCS2/CCS1/GBT
Dynamic Load Balancing
RFID+NFC
4G/WIFI/LAN Port
Credit Card Payment
Fast Charge
IP55 IK10
E-stop Button
Modular Scalability: Invest Smart, Grow Fast
The biggest challenge in deploying Level 3 DC fast charging infrastructure is predicting future power demands. Our proprietary R&D team solved this with a highly advanced modular internal architecture. Operators can initially deploy this station at a cost-effective 60kW or 80kW to service standard passenger EVs. As battery technologies advance and high-capacity logistics trucks enter your network, the system can be effortlessly upgraded to 120kW or 160kW by simply adding modular power blocks. This future-proofs your initial capital expenditure (CAPEX).
High-Visibility Safety for High-Traffic HubsIn busy highway rest stops, logistics depots, and public transit hubs, safety is non-negotiable. The striking Yellow Edition was explicitly designed to provide high-visibility contrast in all weather conditions, from dense fog to dark, heavy-traffic nights. This significantly reduces the risk of accidental vehicular collisions with the charging hardware, protecting your 60kW-160kW investment.
The "Sweet Spot" for ROI: The 60kW-80kW range is the industry's "golden ratio" for commercial charging. It delivers rapid power for urban dwell times (30–60 minutes at supermarkets, gyms, or restaurants) while significantly lowering initial grid upgrade costs compared to ultra-high power units.
Heavy-Duty Industrial Build: Weighing 120kg with a reinforced IK10 impact-resistant chassis, the PDB series is built for the rigors of high-traffic public use, offering far greater physical stability than lighter wall-mounted units.
Superior Thermal Management: Engineered for continuous high-load operation, featuring independent cooling ducts and an intelligent derating mechanism that maintains peak performance even in ambient temperatures up to 55°C.
Certified Safety Standards: Fully compliant with IEC 62955, featuring integrated Type A + 6mA DC residual current protection and ±2% billing-grade energy metering for secure and transparent commercial transactions.
| Parameter | Specification |
| DC Output Power | 60kW (120A) / 80kW (160A) |
| Charging Connector | IEC 62196 CCS 2 (Dual-gun options available) |
| Input Power Supply | 400VAC ± 15%, 50/60Hz |
| Grid Compatibility | TN / TT / IT Systems |
| Protection Suite | UVP, OVP, OCP, Relay Stuck Protection, Over-Temperature |
| Residual Current Protection | Integrated Type A + 6mA DC (Per IEC 62955) |
| Parameter | Specification |
| Form Factor | 700 * 425 * 1500 mm (Standard Floor-mounted Pedestal) |
| Net Weight | 120 kg (High-stability structural steel) |
| Environmental Rating | IP55 (Weatherproof) & IK10 (Vandal-resistant) |
| Operating Range | -30°C to 55°C (Smart derating) | Altitude up to 2500m |
| Energy Metering | Industrial grade with ±2% Accuracy |
| Parameter | Specification |
| Communication Interface | WiFi / 4G / Ethernet |
| User Authentication | RFID Card, Mobile App, and Plug & Charge |
| Backend Protocol | OCPP 1.6 JSON (CMS & Billing Ready) |
| Remote Maintenance | OTA (Over-the-Air) updates via App or OCPP |
| HMI Interface | Branded Logo LED & Multi-color Status LED Indicators |
| Maximum Power | 60kw/120A 400VAC±15%；80kW/160A 400VAC±15% |
| Connector | CCS1/CCS2/GBT |
| Dimension (H*W*D) | 700*425*1500 mm |
| Display | LED Touch 10.1″ |
| Installation | Floor-mount |
| Certification | CE |
| Ingress Protection | IP55,IK10 |
| Dynamic Load Blancing | Solar Charging |
| Our Services | 1.OEM/ODM Support |
| 2.2-Year Warranty | |
| 3.10-15 days lead time | |
| 4.Rigorous Quality Control | |
| 5.Industry-Leading Manufacturer |
Featuring card payment, APP control, OCPP 1.6 compatibility, WiFi/4G/Ethernet connectivity, and dual 60/80 kw outputs, our charging station offers a seamless EV charging experience.
Equipped with leakage, overvoltage, overtemperature, lightning, and waterproof protections, our charging stations ensure safe, reliable charging for your EV. Use with confidence.
Product Description：
In the ever-expanding world of electric vehicles (EVs), charging technology is a pivotal aspect of ensuring a seamless and efficient driving experience. PENODA, a renowned name in the field of advanced charging solutions, proudly presents the PENODA 60/80kW DC EV Charger. This cutting-edge charger is designed to meet the demands of the modern EV landscape, offering speed, efficiency, and versatility like never before.
The 60/80kW DC EV Charger is a high-power charging solution designed for electric vehicles. This charger, known for its impressive 60-80 kilowatt output, offers a range of features that make it a top choice for EV owners. Smart charging protection system, automatic detection of abnormal states, intelligent control current.
High Power Output: With a substantial 60-80 kilowatt output, this charger is significantly faster than standard home chargers.
Compatibility: It’s compatible with a wide range of EVs, making it a versatile choice.
Fast Charging: Thanks to its high power, it can deliver a substantial charge in a relatively short time.
Safety: The 60/80kW DC EV Charger comes equipped with safety features like overvoltage protection and short-circuit prevention.
The 60/80kW DC EV Charger is a game-changer in the world of electric vehicle charging. Its high power output, compatibility, and safety features make it a top choice for EV owners looking for fast and efficient charging solutions. As EV adoption continues to grow, expect to see more of these chargers in public charging stations, making longer journeys more accessible for all EV enthusiasts. Make the switch to a 60/80kW DC EV Charger today and enjoy quicker, more efficient charging for your electric vehicle. Place your order now.
Enterprise-Grade Architecture & Highway Dominance
1. Scalable Power Output (60kW to 160kW): Unmatched flexibility. Start with 60kW or 80kW and seamlessly expand to 120kW or 160kW using our proprietary modular power blocks, eliminating the need to rip out and replace entire stations as demand grows.
2. High-Visibility Industrial Enclosure: Built for the harshest environments. The vibrant yellow IP55/IK10 metal chassis acts as a vital safety feature for bustling fleet depots, preventing accidental impacts while withstanding extreme weather.
3. 100% In-House R&D & Custom OEM: Produced entirely in our TUV and ISO certified factory, we offer unrestricted OEM and ODM customization for CPOs and enterprise brands looking to dominate regional highway networks.
4. 7-Inch HD Interactive Hub: A premium 7-inch anti-glare touch screen provides crystal-clear instructions and real-time charging metrics, maintaining perfect visibility even under direct, glaring highway sunlight.
5. Frictionless Payment & Smart Start: Eliminate queues at busy service stations. Drivers can initiate ultra-fast charging instantly utilizing RFID cards, NFC, QR code scanning, a dedicated smart APP, or the cutting-edge ISO 15118 Plug & Charge protocol.
6. Bank-Grade Security & OTA Diagnostics: Fully integrated with 4G, Wi-Fi, and LAN. It communicates via the OCPP 1.6J backend protocol with strict TLS 1.2 encryption, allowing facility managers to perform Over-The-Air (OTA) updates and proactive remote diagnostics securely.
Highway Rest Stops & Service Stations: Deliver the ultra-fast 120kW/160kW turnaround times that cross-country travelers and commercial logistics drivers demand.
Heavy-Duty Fleet Depots: The perfect high-visibility charging hub for electric buses, delivery trucks, and municipal utility vehicles that require massive, reliable power.
Large-Scale Public CPO Networks: Leverage the scalable 60kW-to-160kW architecture to roll out wide-ranging public infrastructure that grows alongside local EV adoption rates.
Models: 60kW / 80kW / 120kW / 160kW
1. Preparation & Electrical CapacityBefore installation, verify that the site’s power supply supports 380VAC ± 15% (3-Phase, 5-Wire). Ensure the electrical infrastructure meets the following minimum rated input current requirements:
60kW Model: Minimum 120A
80kW Model: Minimum 160A
120kW Model: Minimum 240A
160kW Model: Minimum 320A
2. Floor-mount InstallationThis equipment is designed for floor-mount installation. A level and stable concrete foundation must be prepared in advance. Complimentary specialized expansion bolts are included with the unit to securely anchor the station to the ground.
3. Electrical WiringWith the main power supply switched OFF, connect the input cables (L1, L2, L3, N, and PE). All terminal screws must be tightened to the specified torque. Ensure the PE (Earth) wire is solidly grounded to guarantee operational safety.
4. Network & Smart ConfigurationEstablish a network connection via WiFi, 4G, or Ethernet to activate the OCPP 1.6J intelligent management system. This enables remote monitoring, data management, and APP-based control.
5. Commissioning & OperationConfirm that the Emergency Stop button is released. Switch on the circuit breaker. Once the 10.1-inch touch screen displays the "Ready" status, initiate a test charge using an RFID card or the mobile APP.
WARNING: Installation must be performed by a certified professional electrician in accordance with local electrical codes and safety regulations.
It dramatically lowers your initial capital risk. You can install the station at 60kW or 80kW today. When larger EVs or heavier traffic require faster charging, you simply upgrade the internal modules to 120kW or 160kW without needing to purchase a completely new charging station.
Beyond showcasing our extensive OEM/ODM color customization, the high-visibility yellow enclosure is a critical safety asset. It ensures the powerful, floor-mounted station is easily spotted by drivers of large trucks or buses in busy, high-traffic, or dimly lit environments, preventing costly accidents.
Yes. The entire system—from the scalable DC power modules to the rugged IP55/IK10 enclosure and the software management system—is developed by our proprietary R&D team and built in our TUV and ISO certified factory, guaranteeing industrial-grade reliability.
We provide a frictionless experience via the vivid 7-inch touch screen. Drivers can authenticate and start charging using RFID, NFC, QR Code scanning, a smart APP, or the highly advanced ISO 15118 Plug & Charge technology.
Security is our top priority for large-scale infrastructure. The station connects via 4G, Wi-Fi, or Ethernet and utilizes the global OCPP 1.6J standard. All commercial data, billing, and remote Over-The-Air (OTA) commands are rigorously encrypted with TLS 1.2 to prevent cyber threats.
